CUV-090S036SP 90W 36V Constant Voltage Power Supply
- Excellent Thermal Performance up to 65°C Ambient Temperature
- Input Surge Protection:10kV DM, 10kV CM
- No Load Power Consumption ≤0.15W
- Withstands 10G Vibration Test
- Class I Power Supply
- Complies with Limited Power Source (LPS)
- Operating Altitude up to 5,000m
- 5 Year Warranty
Descriptions：
The CUV-090S036SP is a 90W, constant-voltage power supply that operates from 90-305 Vac input with excellent power factor and harmonic. It is created for outdoor telecommunication and security equipment requiring industry safety compliance. The high efficiency of the power supply and compact metal case enables them to run cooler, significantly improving reliability and extending product life. To ensure trouble-free operation, protection is provided against input surge, over current, output over voltage, over temperature, and short circuit.
Specs
Models
Specs
-
Life Time
107,000 hours @ Case Temperature 50°C -
Dimensions
Inches (L x W x H) 6.85 x 2.66 x 144 Millimeters (L x W x H) 174 x 67.5 x 36.5 -
Certifications
Models
| Output Voltage | Input Voltage Range | Output Current Range | Max. Output Power | Model Number |
| 36 V | 90 ~ 305 Vac | 0 – 2.5 A | 90 W | CUV-090S036SP |
